ChipScan-Scanner is an evaluation software designed for reliable acquisition, fast interactive visualization and sophisticated analysis of electromagnetic compatibility (EMC) measurements of components. In combination with a Langer IC-Scanner and one of Langer’s ICR microprobes, ChipScan-Scanner is a versatile tool for mearuring high-frequency magnetic or electric fields up to 6 GHz of integrated circuits, PCBs and even complete products.
Technical parameters
System requirements
Operating system
Windows 10/8/7 64-bit (latest service packs)
Monitor resolution
(1280 x 1024) px
HD space
1 GB
Recommended system requirements
Processor
Intel Core i7 2.7 GHz
Memory
8 GB
Graphics card
AMD Radeon 7950
Graphics memory
3 GB
Supported spectrum analyzers
The following lists contain all spectrum analyzers supported by ChipScan-Scanner, the appropriate supported interfaces (RS232, GPIB1, Ethernet), the firmware version and additional important notes regarding the specific model. If you do not find your spectrum analyzer in the list please contact our sales team for available options using the following email address mail@langer-emv.de.
We are making great efforts to develop our drivers and are testing them intensively. Due to different available firmwares for specific spectrum analyzer models we can not guarantee to 100 percent that all spectrum analyzers in these lists are working without any errors.
Meaning of icons: driver fully tested, driver in test phase.
Advantest
Modell
RS232
GPIB
Ethernet
Firmware
Notes
R3131
R3131A
R3132
R3272
no hardcopy
U3741
U3751
U3771
U3772
GW Instek
Modell
RS232
GPIB
Ethernet
Firmware
Notes
GSP9300B
no hardcopy, no tracking generator
GSP9330
V3.0.0.6
no hardcopy, no tracking generator
Keysight (former Agilent)
Modell
RS232
GPIB
Ethernet
Firmware
Notes
E4401B
ESA-E series
E4402B
ESA-E series
E4403B
ESA-L series
E4404B
A.07.05
ESA-E series
E4405B
ESA-E series
E4407B
ESA-E series
E4408B
ESA-L series
E4411B
ESA-L series
E7401A
A.02.00
EMC series
E7402A
EMC series
E7403A
EMC series
E7404A
EMC series
E7405A
A.14.04
EMC series
N9000A
A.07.06
CXA series
N9000B
A.20.18
CXA series
N9010A
A.14.06
EXA series
N9010B
A.19.55
EXA series
N9020A
A.10.52
MXA series
N9020B
A.25.08
MXA series
N9021B
N9030A
A.07.04
PXA series
N9320B
0B.03.43
no hardcopy, no preset, no uncal
Rigol
Modell
RS232
GPIB
Ethernet
Firmware
Notes
DSA815
00.01.08.00.03
slow data aquisition
Rohde & Schwarz
Modell
RS232
GPIB
Ethernet
Firmware
Notes
ESL3
1.83 SP4
ESL6
ESPI3
no tracking generator yet
ESPI7
4.42
no tracking generator yet
ESR3
no tracking generator yet
ESR7
2.27 SP1
no tracking generator yet
ESR26
no tracking generator yet
ESRP3
no tracking generator yet
ESRP7
2.26
no tracking generator yet
ESU8
4.43
hardcopy via GPIB only, no tracking generator yet
ESU26
hardcopy via GPIB only, no tracking generator yet
ESU40
hardcopy via GPIB only, no tracking generator yet
ETL3
1.73
FPC1000
XVI via USB supported
FPC1500
no tracking generator yet
FPL1003
1.51
FPL1007
1.51
FPL1014
FPL1026
FSEK30
3.40.2
FSH4
no tracking generator
FSH8
V2.50
no tracking generator
FSH13
no tracking generator
FSL3
2.00 SP2
FSL6
1.80 SP1
FSL18
1.80 SP1
FSP3
FSP7
4.50
FSP13
2.80
FSP30
FSP31
FSP40
FSU3
no tracking generator yet
FSU8
no tracking generator yet
FSU26
4.37
no tracking generator yet
FSU31
no tracking generator yet
FSU32
no tracking generator yet
FSU43
no tracking generator yet
FSU46
no tracking generator yet
FSU50
no tracking generator yet
FSU67
no tracking generator yet
FSUP8
FSUP26
4.37
FSUP50
FSV3
1.50
FSV7
FSV13
1.50
FSV30
FSV40
FSW8
4.30 SP1
FSW13
4.30 SP1
FSW26
4.30 SP1
FSW43
4.30 SP1
FSW50
4.30 SP1
FSW67
4.30 SP1
FSW85
4.30 SP1
HMS-X
SW02.250
no tracking generator yet, analyzer is sometimes not recognized by the device search at the first attempt
driver fully tested,
driver in test phase.
